Holly Vine panel 2000 × 500 × 30 mm
Made to order
Data sheet
| Size | 2000 × 500 mm |
|---|---|
| Thickness | 30 mm |
| Weight | 57 kg |
| Reinforcement | welded steel mesh Ø3 mm + fibreglass |
| Concrete | C35/45 |
| Water absorption | ≤ 6 % |
| Reaction to fire | Class A1 |
| Durability | over 40 years |
| Availability | Made to order |
Material price
Excluding VAT, excluding delivery and installation. Installation is quoted per linear metre — see price per metre.
| Grey concrete | 25 €/m² excluding VAT |
|---|---|
| White concrete | 33 €/m² excluding VAT |
Delivery is not included in these prices. Delivery of the material to the site is quoted separately, by municipality and volume.
Compatibility
| Post groove | Panel that fits |
|---|---|
| 30 mm | 30 mm panel |
| 40 mm | 40 mm panel and double-sided panel (two 20 mm panels) |
| Wall height | Panels per segment | Post |
|---|---|---|
| 1.50 m | three 500 mm panels | 2200 mm post |
| 1.80 m | three 500 mm + one 300 mm | 2800 mm post |
| 2.00 m | four 500 mm panels | 2800 mm post |
| 2.50 m | five 500 mm panels | 3300 mm post |
This panel is 30 mm, so it requires a post with a 30 mm groove. The segment is 2.0 m: the 2000 mm panel fits whole between two 120 × 120 mm posts. Intermediate heights are made by combining the 300 mm panel with the 500 mm ones.
Request a free quote
Just leave your name and phone number — that is enough for us to get back to you. If you tell us the municipality, the length and the height, we will reply straight away with a price and with the lead time for the material.
